12 Core Bundle Pigtail Fiber Optic Patch Cord 1 Meter Customized Length FTTH Fiber Optic Jumper
| Core: | Multicore | Model NO.: | Bundle Fan-out Fiber Optic Pigtails |
| Sheath Material: | LSZH Or PVC | Transport Package: | Single Pack |
| Trademark: | Fiberlink Or Customized | Use:: | FTTH, FTTH |
| Fiber Dimension:: | 0.9mm 2.0mm 3.0mm | ||
| High Light: | Customized Length Fiber Optic Patch Cord,12 Core Fiber Optic Patch Cord,FTTH Fiber Optic Jumper |
||
Features
High precision LC connector series with competitive pricing
Provide high density mounting in any optical equipment
Excellent optical performance
Available for both SM, MM, simplex and duplex
0.9mm, 2.0mm, 3.0mm cable diameter optional
Applications
Telecommunication
Testing equipment
Long-haul telecommunication
LAN system
CATV systems
Specifications
| Connector Type | SC, LC, FC, ST, MU |
| Fiber Type | G652D, G657A, OM1, OM2, OM3, OM4 |
| Polish or Ferrule Interface Type | PC, UPC, APC |
| Jacket Material | PVC or LSZH |
| Cable Diameter | 0.9mm, 1.6mm, 1.8mm, 2.0mm, 3.0mm |
| Jacket Color (Multimode: OM1 & OM2) | Orange |
| Jacket Color (Multimode: OM3) | Aqua |
| Jacket Color (Multimode: OM4) | Aqua or Purple |
| Jacket Color (SingleMode: G652D & Gb57A) | Yellow |
| Insertion Loss (dB) Max. | ≤0.3 |
| Return Loss (dB) Singlemode | PC≥45, UPC≥50, APC≥60 |
| Return Loss (dB) Multimode | PC≥35dB |
| Note:Other Jacket colors may be available upon request. | |
Ordering Information
Using the available configurations amend/create product codes using the formula below.
Part Number: PT-AA-BCDE
Ordering Guide
| AA | B | C | D | E |
| connector Type | Fiber Type | Length | Jacket Material | Jacket Color(CL) |
| FP,SP,SA,LP | OM1=62.5/125 OM1 OM2=50/125 OM2 OM3=50/125 OM3 OM4=50/125 OM4 G652D=9/125 G652D G657A=9/125 G657A |
01=1M 02=2M 03=3M 10=10M |
1=PVC 2=LSZH |
Yellow=YE Orange=OR Aqua=AQ Purple=PU |
-
