Blue color ROHS Quadplex LC / UPC with shutter fiber optic cable adapter

Blue color ROHS Quadplex LC / UPC with shutter fiber optic cable adapter
Blue color ROHS Quadplex LC / UPC with shutter fiber optic cable adapter
video play

Large Image :  Blue color ROHS Quadplex LC / UPC with shutter fiber optic cable adapter

Product Details:
Place of Origin: Shenzhen , China
Brand Name: CY COM
Certification: ISO9001:2015 , RoHS
Model Number: Quadplex LC/UPC shuttered adapter
Payment & Shipping Terms:
Minimum Order Quantity: 100pcs
Price: USD0.12-0.8/PCS
Packaging Details: Plastic Box
Delivery Time: in 5-10 days
Payment Terms: L/C,T/T,Western Union payments for offline orders.
Supply Ability: 4.5 MIllion PCS / Month
Detailed Product Description
Certification: ISO9001:2008 Color: Blue
MOQ: 100pcs
High Light:

fiber optic coupler

,

optical fiber adapter



Quadplex LC / UPC fiber optic cable adapter with shutter , RoHS certification



Description:

Quad LC adapter with shutter is a mechanical device designed to align fiber-optic connectors. It contains the interconnect sleeve, that holds the two ferrules together.

Characteristics:

  • Low insertion loss
  • Good repeatability and interchangeability
  • Good environmental stability

Order information:

  • For example: SC/APC-SM-SX-with shutter-plastic
  • Connector type: FC, SC, LC, ST, MPO, MTRJ, MU, E2000, D4, DIN, SMA
  • Ferrule end-face: PC, UPC, APC
  • Core type: single-mode (SM: 9/125μm), multimode (MM: 50/125μm or 62.5/125μm)
  • Appearance: with ear type, no ear type
  • Materials: copper alloy, zinc alloy, plastic

Technical Specification:



rameter Unit LC, SC, FC, MU, ST, SC-ST, FC-ST, FC-SC, MTRJ E2000
SM MM SM MM SM
PC UPC APC PC PC UPC PC PC APC
Insertion Loss (Typical) dB ≤0.3 ≤0.2 ≤0.3 ≤0.2 ≤0.3 ≤0.2 ≤0.2 ≤0.3 ≤0.3
Return Loss dB ≥45 ≥50 ≥60 ≥30 ≥45 ≥50 ≥35 ≥55 ≥75
Exchangeability dB ≤0.2 ≤0.2 ≤0.2
Repeatability dB ≤0.2 ≤0.2 ≤0.2
Durability Time >1000 >1000 >1000
Operating Temperature -40~75 -40~75 -40~75
Storage Temperature -45~85 -45~85 -45~85







Blue color ROHS Quadplex LC / UPC with shutter fiber optic cable adapter 0
